Turbine Wheel-Pointer Indicator DPE-..Z3

Có: 0 sản phẩm trong giỏ

Turbine Wheel-Pointer Indicator DPE-..Z3
  • Mã SP: BDLKB-DPE-Z3
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 1740
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Measuring range: 7-30 L/min ...100-750 L/min water
Connection: G ½... G 3, ½ NPT...3 NPT
Material: aluminum/bronze, st. st.
Max. pressure: 40 bar
Max. temperature: 80 °C
Accuracy: ± 2,5 % FS
Analogue output, pointer indicator

Flow meter model  DPE is used for measuring and monitoring liquids. The device works according the well-known blade wheel principle. The six vane blade wheel is retained axially in a high-quality saphire bearing. The sensor is supplied ready-to-install with pipe fittings or with weld-on sleeves.

The blade wheel is set in motion by the flowing medium. Magnets are embedded hermetically sealed in  the ends of the blade wheels. The magnets generate electrical pulses in a Hall-effect sensor mounted out-side the flow area.
