fuel meter
  • Mã SP: AAKMN-FMO
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 13067
  • oval gear mechanism for optimum accuracy
    low pressure drop allows for gravity and in-line applications
    register cap can be removed and rotated for easy display reading
    supplied with integrated mesh strainer
    4-digit resettable batch totaliser (max 999.9 units)
    6-digit accumulative totaliser
    available in Litre, US Gal, UK Gal calibration
    HA1S fuel filter (10μm) available separately
    fully serviceable
    10 year warranty and parts guarantee
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
  • compatible fluids (DM100 and DM150): diesel , kerosene and petrol
  • compatible fluids (DM100BD): biodiesel
  • compatible fluids (HA1S): diesel, kerosene and petrol
  • wetted components (DM100): aluminium, zinc plated carbon steel, PEI Resin, viton
  • wetted components (DM100BD): aluminium, nickel plated carbon steel, PEI Resin, viton, acetal resin
  • accuracy: ± 1% of reading
  • flow range: 3 - 80 L/min (0.8 - 21 US gal/min)
  • max. pressure: 1 000 kPa (145 psi, 10 bar)
  • max. temp: 80° C (176° F)
  • inlet thread: 1” BSPT, 1” BSPPL(G) or 1” NPT female
  • outlet thread: 1” BSPT, 1” BSPPL(G) or 1” NPT female
  • weight: 1.2 kg (2.6 lbs)
