Variable Area Flow meter-Low Volume
  • Mã SP: BDAKB-KDF/KDG
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 7468
  • Measuring range: 0,25 - 2,5 ... 16 - 160 L/h water
    0,5 - 5 NL/h ... 500 - 5000 NL/h air
    Connection: ¼ NPT, G ¼ female
    Material: st. steel
    Max. pressure: 16 bar
    Max. temperature: 100 °C
    Accuracy: ± 2,5% qG=50%
    Option: contacts, up/downstream diff. pressure regulator
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền

Measuring range: 0,25 - 2,5 ... 16 - 160 L/h water
0,5 - 5 NL/h ... 500 - 5000 NL/h air
Connection: ¼ NPT, G ¼ female
Material: st. steel
Max. pressure: 16 bar
Max. temperature: 100 °C
Accuracy: ± 2,5% qG=50%
Option: contacts, up/downstream diff. pressure regulator

The flow meters and switches for very low flows model KDF and KDG for liquids and air operate on the suspended float principle: that is, the installation position is vertical and the direction of flow is from bottom to top. The instruments have been designed as simple and thus economical measuring systems. The float is a ball, whereby the indication point is the upper edge of the ball. A needle valve is fitted as standard.
