Oscillation-Meter/Switch DOG-1
  • Mã SP: BDCKB-DOG-1
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 10185
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Range: 0,2-20...160-16.000 m³/h air
Connection: flange: DN25... 400
Material: cast steel, steel, stainless steel
Pmax: PN40 bar
Tmax: 120°C
Accuracy: +/- 1.5 % of measured value (air)
Pulse & analogue output,
digital display for flow measurement and counter
 Flow meter DOG-1 and DOG-3 are used for non-contact flow measurement of gases. The medium flows through an orifice in a tube. Bypass bores are located at the sides. The dynamic pressure at the orifice causes part of the gas volumetric flow to flow into the bypass. The division ratio remains constant over the whole measuring range.
