Paddle Switch-Polysulfone PPS
  • Mã SP: BDCKB-PPS
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 4100
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
 Switching range: 36...108 L/min water (rising)
18...72 L/min water (falling)
Connection: G 1, 1 NPT for DN 32 ...DN 80
Material: polysulfone
Max. pressure: 10 bar
Max. temperature: 105 °C
Adjustable accuracy: ± 20 % FS
The flow monitor PPS is a flow monitor for nominal pipe sizes greater than NW 32. Fluid flow (regardless of direction) deflects the paddle and over an eccentric moves a magnet holder fitted to a permanent magnet. The magnet actuates non-contacting a dryreed switch embedded in the switching tube. The paddle switch is available with N/O, N/C or changeover contact. The inlet and outlet pipe section should be approximately three times the nominal size of the piping. The flow monitor can be fitted in a standard T piece or reducing pipe. Ideally the flow monitor should be fitted in horizontal piping.
