Rotating Vane-Pointer Indicator DRG-..Z3

Có: 0 sản phẩm trong giỏ

Rotating Vane-Pointer Indicator DRG-..Z3
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5495
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Measuring range: 0,5-12 L/min ...10-140 L/min water
Connection: G 1/8... G 1, 1/8 NPT.. 1 NPT
Material: aluminum-bronze, st. st., Polypropylen
Max. pressure: 40 bar
Max. temperature: 80 °C
Accuracy: ± 3 % FS
Analogue output, pointer indicator

Rotating vane flow meters series DRG are used for measuring and monitoring low viscous liquids. Series DRG flow meters are working according the well-known rotating vane principle. A magnet fitted in the vane and hermetically sealed from the medium transfers non-con-tacting the rotary motion to a Hall-effect sensor mounted in the housing. The sensor converts the rotary motion which is proportional to the flow to a frequency signal. A series-con-nected electronics unit converts the signal to an analogue output, limit contacts or display.
