Pressure and level transmitter PASCAL CV LEVEL

Có: 0 sản phẩm trong giỏ

Pressure and level transmitter PASCAL CV LEVEL
  • Mã SP: BDBLB-PALTD
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 7187
  • Pressure transmitter monitoring for vessels and tanks designed to minimize process temperature errors.
    With the next generation LTC membrane (LTC = Low Temperature Coefficient), the temperature coefficient of the diaphragm seal is compensated.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Modular pressure and level transmitter temperature compensation up to 0.1 mbar / 10 K by LTC-technology
    Output signal:
    ● 4…20 mA
    ● HART® protocol (rev. 6), option
    ● PROFIBUS PA
  • Function modules
    ● Multifunctional display
    ● Switching module with 2 floating channels
  • Function module replacement on site without recalibration “plug and measure”
  • Limits of measuring range 0…80 mbar to 0…40 bar
  • Accuracy: ≤ 0.15 %
  • Turndown 5:1
  • Medium temperature up to 160 °C
  • Various process connections available
  • Mechanically robust stainless steel membrane
Options
  • Explosion protection for gases and dust
  • Classification per SIL 2
  • Calibration certificate 5 measuring points acc. to DINEN 10204-3.1
  • Material certificate acc. to DIN EN 10204-3.1
Application area

● Chemical and petrochemical industry
● Pharmaceuticals
