  • Control up to 500 slpm (nlpm) with 4.5 psid (310 mBard)
  • High accuracy (+/- 1.0 % of full scale)
  • Highly repeatable (+/- 0.2% of full scale)
  • True linear performance (+/- 1.0 % of full scale in 10 standard gases)
  • 10 different gases using Dial-A-Gas® Technology
  • Precision digital PID valve control;no valve tuning or adjustment
  • Control valve with large flow coefficient (Cv) for precise control at low ΔP
  • Patented, inherently linear Laminar Flow Element (LFE)
  • Advanced platinum sensor technology
  • All 316 stainless steel construction
  • Unique Pilot Module (mounted or hand-held) allows these control functions:
  • Gas type
  • Setpoint value
  • Setpoint source
  • Engineering units
  • Output signal
  • Valve state (open, closed or automatic
  • Full scale value
  • Zero Value
  • Span Value
  • Avoid recalibration by re-zeroing and re-spanning in the field
  • Multiple outputs (both analog and digital)
  • Optional Compod™ adds MODBUS RTU multi-drop capability
  • Primary standard calibration, NIST-traceable certification
